Elegance LED 4-Zone Receiver 5...36V 192W WiFi + RF 2,4GHz monochrome; 2-Pin
Available, delivery time: 1-3 days
Article-No.:
IT-007665
Shipping weight:
0.055 kg
Shipping Zone:
50
ROHS:
Ja
Product description
| ✔ The RF Wall Touch Controller can only be used in conjunction with the corresponding MiLight 4-Zone receivers! |
| ✔ The RF Wall Touch Controller can only be used in conjunction with the corresponding MiLight 4-Zone receivers! |
| ✔ The RF Wall Touch Controller can only be used in conjunction with the corresponding MiLight 4-Zone receivers! |
| ✔ The RF Wall Touch Controller can only be used in conjunction with the corresponding MiLight 4-Zone receivers! |
| ✔ Up to 4 MiLight 4-Zone controllers can be controlled INDEPENDENTLY (switchable to common control) |
Technical specifications
| Control unit type: | Elegance 4-Zone Receiver |
|---|---|
| Compatibility: | monochrome; 2-Pin |
| Transmission technology: | RF (radio frequency) 2,4GHz |
| Operating voltage: | 5...36V |
| Power @ 12V: | 96W |
| Power @ 24V: | 192W |
| Power @ 36V: | 288W |
| Power @ 5V: | 40W |
| Dimensions Device: | 97x33x18mm |
| Power connection Device: | Screw terminals |
| Connection LED: | Screw terminals |
