Proximity switch Inductive 18mm M18 NPN NC contact 6...36V DC IP67 Sensor Brass nickel-plated -30...+65°C

Available, delivery time: 1-3 days

Article-No.: IT-008244
Shipping weight: 0.08 kg
Shipping Zone: 50
ROHS: Ja
Quantity Unit price
1 - 10
€5.50*
11 - 20
€5.39*
21 - 50
€5.28*
51 - 100
€5.23*
101 - 200
€5.17*
From 201
€5.12*

Prices incl. VAT plus shipping costs

Stk
aktueller
Bestand
Product description
Diameter18mm M18
Sensor technologyInductive
PolarityNPN
Switching contactNC contact
Voltage6...36V DC
Total length68mm
ConnectionCable 120cm (3 wire)
Detection range< 8mm
Switching current200mA
Insulation resistance50 MOhm
Protection classIP67
Casing MaterialBrass nickel-plated
Temperature range-30...+65°C
Technical specifications
Sensor technology: Inductive
Polarity: NPN
Switching contact: NC contact
Voltage: 6...36V DC
Switching current: 200mA
Insulation resistance: 50 MOhm
Detection range: < 8mm
Temperature range: -30...+65°C
Protection class: IP67
Casing Material: Brass nickel-plated
Connection: Cable 120cm (3 wire)
Diameter: 18mm M18
Total length: 68mm
